2017 Siemens SGT-400 / Centrax CX400 Gas Turbine Generator Package – 12.9 MW, 50 Hz, 11 kV

For sale: 2017 Siemens SGT-400 gas turbine generator with Centrax CX400 packaging, advertised at 12.9 MW, configured for 50 Hz, 11 kV, three-phase power generation. The package has approximately 5,000 cumulative operating hours, including testing and commissioning during its original installation in France, and is currently assembled at its present site.

This industrial gas turbine package includes a twin-shaft engine with dry low emissions (DLE) combustion, an AC generator, reduction gearbox, acoustic enclosure, control systems and supporting auxiliaries. The described supply also includes Centrax SCADA, an auxiliary transformer, medium voltage switchgear, a low voltage distribution panel and a 125 VDC, 40 A charger.

Main Specifications

• Turbine manufacturer: Siemens
• Turbine model: SGT-400 / SGT 400
• Package manufacturer: Centrax
• Package model: CX400 / CX 400
• Year: 2017
• Advertised power output: 12.9 MW — subject to nameplate verification
• Operating hours: Approximately 5,000
• Condition: Previously operated; currently assembled
• Frequency: 50 Hz
• Generator voltage: 11,000 V / 11 kV
• Generator configuration: Three-phase, four-pole
• Power factor: 0.8
• Gearbox output speed: 1,500 rpm
• Turbine design: Twin-shaft, hot-end drive
• Combustion system: Dry low emissions

**Turbine, Gear
